Gasboard-3000Plus is designed with patented Micro-flow infrared technology and able to measure concentration of SO2, NO, CO, CO2, CH4 simultaneously, especially suitable for emission measurement from various stationary sources. Furthermore, it can combine NDUV technology together to measure NO2 directly, which enables Gasboard-3000Plus to realize optical measurement of NO+NO2 at same time. It is an ideal solution in fields for emission monitoring from boilers, power plants, cement p...

The continuous emission monitoring system is based on innovative micro-flow NDIR technology to measure the SO2, NO, CO, CO2 and O2 (ECD or paramagnetic) five gases at the same time. Eliminate the ambient’s temperature influence on measurement value and less interference of water vapor on SO2 and NO measurement. It has excellent prolonged stability and less cross interference.

Cubic Instruments (a wholly-owned subsidiary of Cubic sensor) independently developed Gasboard-3000GHG greenhouse gas emission analyzer. Adopting the independent intellectual property rights of Micro flow NDIR dual-chamber sensor technology (international PCT patent PCT/CN2018100767), Cubic Instruments online greenhouse gas emission analyzer Gasboard-3000GHG can accurately measure the greenhouse gases concentration change of CO2, CH4, N2O etc and CO gas in flue gas at the same time. The range c...

Cubic Instruments Gasboard-9805 is a Portable Emissions Measurement System (PEMS) which is used to measure emissions from combustion engines in real driving. It utilizes three different PEMS modules, including PEMS-GAS for measuring the concentrations of gas emissions (CO, CO2, THC, NO, NO2), PEMS-PN for measuring particulate matter, and PEMS-EFM for measuring exhaust flow rate. As part of the basic measurements, Gasboard-9805 can also collect location data ...

Gasboard-5020 emission gas analyzer is designed for measuring the emissions of all gasoline, LPG or CNG vehicles, it is developed based on dual beam non-dispersion infrared (NDIR) principle to measure CO, CO2, HC, and electrochemical sensors to measure O2 and NO. The test reports can be printed on the built-in printer. Gasboard-5020 is equivalent with OIML R99 class 0 standard, very suitable for cars, motorcycles, and other light duty, heavy duty vehicles exhaust inspection and then optimize ...

Gasboard-2200 UV-DOAS NOx gas bench adopts high-precision ultraviolet differential absorption spectroscopy gas analysis technology to measure NO & NO2 simultaneously. It’s widely used by gas analyzers and PEMS manufacturers due to its flexible integration, high quality and easy maintenance.

Gasboard-3100P is a portable syngas analyzer based on NDIR ,TCD and electrochemical technology, it can simultaneously measure CO, CO2, CH4, H2 , O2 , CnHm, C2H2 , C2H4 or any of their combination and calculate heat value.

Gasboard-3500UV is the new generation biogas monitoring system that primarily designed based on UV-DOAS technology to measure H2S concentration precisely before and after H2S scrubber, and extended with modular sensor of CH4 (NDIR), CO2(NDIR) and O2 (ECD) to realize online continuously monitoring of biogas quality without purging cycle required.The 2 sampling channels design before and after scrubber enable it to provide an ideal solution to guarantee the H2S scrubber efficiency, protect downstr...

LRGA-6000 is an advanced analysis system mainly composed by the core analysis unit LRGA-3100, gas sampling & conditioning system, and data processing system. It works based on the principle of laser Raman scattering, which enhances, collects, processes and identifies the characteristic Raman scattering spectra of the gas to be measured and quantifies the content,  and can provide online measurement for various gases simultaneously with the shortest response time in seconds. With rugg...
